Kerabit Sokkelilevy (Foundation Panel)

Kerabit Foundation Panel is a black, studded high-density polyethylene (HDPE) panel to protect the damp-proofing of foundations.

Foundation panels and edge trims must be covered as soon as possible after installation to prevent damage during construction.

Accessories for Kerabit Sokkelilevy:

Dimensions/measurements

Kerabit Edge Trim for sealing the air gap
Baros Nail with Plug for lightweight blocks
Kerabit Fastener or Baros Nail with Plug for concrete
Kerabit BIL 20/85 Bitumen Primer for pre-treatment
Kerabit Pato/Radon Strip or Platon Self-Adhesive Membrane for the joint of the foundation wall and the footing

Manufacturer / Manufactured for	Kerabit Oy, Lohja plant
Country of origin	Italy from spring 2022, Russia until February 2022
Conformity marking	CE
Waterproofing	Class W1 (60 kPa, 24 h)
Production material	HDPE, recycled
Structural height	8 mm (+/- 10 %)
Compression strength	190 kPa (–20%) (EN ISO 25619-2 rate 25 mm/min, on 4 studs)
Nominal thickness	0,5 mm
Nominal weight	500 g/m² (+/- 5 %)
Rolls size	1 x 20 m or 2 x 20 m
Tensile strength	>250N/50 mm
Colours	black
Packages / pallet	24 rolls (1 x 20 m) or 12 rolls (2 x 20 m)
Weight / package	approx. 10 kg (1 x 20 m) or approx. 20 kg (2 x 20 m)
Weight / pallet	260 kg

Elongation		>20% longitudinally / >20% laterally
Roll diameter		30 cm

Installation

Before installing the Kerabit Foundation Wall Membrane, it is necessary to install the Kerabit Pato/Radon Strip at the joint of the foundation wall and the footing. Kerabit foundation wall membranes are installed with the studs against the foundation wall, fastened at the top and finished with an edge trim.

Kerabit foundation wall membranes must be covered carefully and as soon as possible after installation to prevent damage during construction.

Storage

Rolls must be stored upright, protected against direct sunlight, at a temperature below 45 °C.
